Neutrik 3-pin XLR Male D-cut Panel Mount - Screw-Down
$18.44
In stock
— ships in 1 business day
Description
This connector is typically used as the standard chassis connectors for loudspeaker/amplifier interconnections. They feature a unique metal locking system, making contact once fully locked. They are versatile, robust and easy to terminate.
Features:
Specifications
Neutrik 3-pin XLR Male D-cut Panel Mount - Screw-Down
This connector is typically used as the standard chassis connectors for loudspeaker/amplifier interconnections. They feature a unique metal locking system, making contact once fully locked. They are versatile, robust and easy to terminate.
Color: Black
Contacts: Gold
Connector Type: XLR
Temperature Range: -30℃ to +80℃
Contact Plating: 0.2 µm Au hard alloy over 2 µm Ni
| Product | Neutrik 3-pin XLR Male D-cut Panel Mount - Screw-Down |
| Color | Black |
| Contacts | Gold |
| Connector Type | XLR |
| Temperature Range | -30℃ to +80℃ |
| Contact Plating | 0.2 µm Au hard alloy over 2 µm Ni |
| Insert | Polyamide (PA 6.6) |
| Locking Element | Steel Ck67 |
| Gender | Male |
| Shell coating | Black KTL |
| Capacitance between contacts | ≤ 4 pF |
| Contact Resistance | ≤ 5 mΩ |
| Dielectric Strength | 1,5 kVdc |
| Insulation Resistance | > 10 GΩ (initial) |
| Rated Current Per Contact | 3 A |
| Rated Voltage | < 50 V |
