6-20R Hubbell Power Cord Connector - Screw on - (HBL5469C)
Click the image to zoom
6-20R Hubbell Power Cord Connector - Screw on - (HBL5469C)
$36.06
In stock
— ships in 1 business day
Description
This 6-20R power cord connector is a 2-pole 3-Wire grounding heavy-duty plug. The tough nylon body provides impact and chemical resistance. The powerful offsetting cord grip clamps on individual conductors and outer cord jackets prevent strain on the terminals.
Specifications
6-20R Hubbell Power Cord Connector - Screw on - (HBL5469C)
This 6-20R power cord connector is a 2-pole 3-Wire grounding heavy-duty plug. The tough nylon body provides impact and chemical resistance. The powerful offsetting cord grip clamps on individual conductors and outer cord jackets prevent strain on the terminals.
No. of Poles: 2-Pole
No. Of Conductors: 3 Wires
Connectivity: Screw Terminals
Material: Polycarbonate
Operating Temperature: Maximum continuous 75℃ and Minimum -40℃ without Impact
| Product | 6-20R Hubbell Power Cord Connector - Screw on - (HBL5469C) |
| No. of Poles | 2-Pole |
| No. Of Conductors | 3 Wires |
| Connectivity | Screw Terminals |
| Material | Polycarbonate |
| Operating Temperature | Maximum continuous 75℃ and Minimum -40℃ without Impact |
| Cable Diameter Range | 0.230 - 0.720 inch |
| Wire Gauge Compatibility | 10-18AWG |
| Power Rating | 20A 250V |
| Phase | Single Phase |
| Hubbel Part No. | HBL5469C |
| 6-20R | Female |
| UL | Compliant |
| CSA | Compliant |
| RoHS | Compliant |
| Package Quantity | 1 |
