Locking C19 to C20 Power Cable - SJT Jacket
Click the image to zoom
Locking C19 to C20 Power Cable - SJT Jacket
$10.19
In stock
— ships in 1 business day
Description
This power cord consists of a C20 male on one end and a locking C19 female on the other end. It is typically used to connect a server to a PDU in a data center environment. The unique lockable C19 female connectors can be used with any standard IEC inlet and guards against accidental disconnection of computers, PDU's, servers and most network devices.
Specifications
Locking C19 to C20 Power Cable - SJT Jacket
This power cord consists of a C20 male on one end and a locking C19 female on the other end. It is typically used to connect a server to a PDU in a data center environment. The unique lockable C19 female connectors can be used with any standard IEC inlet and guards against accidental disconnection of computers, PDU's, servers and most network devices.
Color: Black
Number of Conductors: 3 Conductor
Wire Gauge: 14AWG
Jacket: Heavy Duty SJT
Jacket Fire Rating: FT2
| Product | Locking C19 to C20 Power Cable - SJT Jacket |
| Color | Black |
| Number of Conductors | 3 Conductor |
| Wire Gauge | 14AWG |
| Jacket | Heavy Duty SJT |
| Jacket Fire Rating | FT2 |
| Strain Relief | Molded PVC |
| Temperature Rating | -20 deg C to 105 deg C |
| Connector A | IEC 60320 Locking C19 - c(UL)us |
| Connector B | IEC 60320 C20 - c(UL)us |
| Power Rating | 15 Amp / 250 Volt |
| c(UL)us | Compliant |
| ISO | ISO 9001:2008 |
| RoHS | Compliant |
| Conflict Minerals | Compliant |
| Package Quantity | 1 |
