5-15P to ROJ Power Cable - SJT
Click the image to zoom
5-15P to ROJ Power Cable - SJT
$3.06
In stock
— ships in 1 business day
Description
This power cord consists of a 5-15P male on one end and is un-terminated on the other with the outer jacket removed. These cords are typically hardwired directly to equipment. These cables are constructed with UL mandated inner plastic frame molds to enhance terminal alignment and high quality molds. The connectors premium quality to ensure a snug fit into PDU receptacles. Each assembly is 100% continuity tested and 100% HVT (High Voltage) tested and inspected before shipping.
Specifications
5-15P to ROJ Power Cable - SJT
This power cord consists of a 5-15P male on one end and is un-terminated on the other with the outer jacket removed. These cords are typically hardwired directly to equipment. These cables are constructed with UL mandated inner plastic frame molds to enhance terminal alignment and high quality molds.
Color: Black
Number of Conductors: 3 Conductor
Wire Gauge: 18AWG / 16AWG / 14 AWG
Jacket: Heavy Duty SJT
Jacket Material: 100% Virgin PVC - Polyvinyl Chloride
| Product | 5-15P to ROJ Power Cable - SJT |
| Color | Black |
| Number of Conductors | 3 Conductor |
| Wire Gauge | 18AWG / 16AWG / 14 AWG |
| Jacket | Heavy Duty SJT |
| Jacket Material | 100% Virgin PVC - Polyvinyl Chloride |
| Jacket Fire Rating | VW-1 |
| Strain Relief | Molded 100% Virgin PVC |
| Conductor Material | 100% bare copper |
| Temperature Rating | -20 deg C to 105 deg C |
| Connector A | NEMA 5-15P |
| Connector B | Un-terminated - Outer Jacket Removed |
| Power Rating | 10 Amp / 125 Volt (18AWG)13 Amp / 125 Volt (16AWG)15 Amp / 125 Volt (14AWG) |
| 5-15P | c(UL)us |
| Cable | c(UL)us |
| ISO | ISO 9001:2015 , ISO 14000 |
