DP1.2 Male to HDMI Male Cable, 4K@60Hz, HDR, CEC, HDCP2.2, 3
Click the image to zoom
DP1.2 Male to HDMI Male Cable, 4K@60Hz, HDR, CEC, HDCP2.2, 32AWG - Black
$19.56
In stock
— ships in 1 business day
Description
This cable has a DisplayPort male on one end and a HDMI male on the other. It is used to connect a DP source to a HDMI display. It cannot be used to connect a HDMI source to a DisplayPort monitor.
Features:
Specifications
DP1.2 Male to HDMI Male Cable, 4K@60Hz, HDR, CEC, HDCP2.2, 32AWG - Black
This cable has a DisplayPort male on one end and a HDMI male on the other. It is used to connect a DP source to a HDMI display. It cannot be used to connect a HDMI source to a DisplayPort monitor.
Color: Black
Connector Plating: Nickel
Dimensions: DP connector: 28L x 19.8W x 9.8HmmHDMI connector: 43.2L x 20.8W x 11Hmm
Wire Gauge: 32 AWG
Cable Outer Diameter: 4.9mm
| Product | DP1.2 Male to HDMI Male Cable, 4K@60Hz, HDR, CEC, HDCP2.2, 32AWG - Black |
| Color | Black |
| Connector Plating | Nickel |
| Dimensions | DP connector: 28L x 19.8W x 9.8HmmHDMI connector: 43.2L x 20.8W x 11Hmm |
| Wire Gauge | 32 AWG |
| Cable Outer Diameter | 4.9mm |
| Operating Temperature & Humidity | 0 ℃ to +45℃10% to 90 % RH (no condensation) |
| Storage Temperature & Humidity | 0℃ to +70℃10% to 90 % RH (no condensation) |
| Connector A | HDMI Male |
| Connector B | DisplayPort Male |
| DisplayPort | DP Version 1.2 DP1.2 Alt mode with 21.6Gbps all lanes per lane 5.4 Gbps (HBR2), 2.7 Gbps (HBR) and 1.62 Gbps (RBR) |
| HDMI | Up to HDMI max 4K/60Hz, 8bit, 18GbpsSupports RGB 4:4:4, YCbCr 4:4:4 ,4:2:2 ,4:2:0Supports 8bit/10bit/12bit deep colorSupports HDRSupports HDCP2.2&1.4Supports CEC |
| FCC, CE | Approved Cable |
| RoHS | Compliant |
| Reach | Compliant |
| Conflict Minerals | Compliant |
