8-Port DVI Video Splitter, Resolution 4096x2160@30Hz
Click the image to zoom
8-Port DVI Video Splitter, Resolution 4096x2160@30Hz
$278.13
In stock
— ships in 1 business day
Description
This 1x8 DVI splitter enables you to display one DVI source to eight DVI displays simultaneously. It is typically used to connect DVI sources such as DVD players, Blu-ray players, satellite receivers or gaming systems to DVI displays such as HDTVs, HD projectors or DVI monitors.
Features
Specifications
8-Port DVI Video Splitter, Resolution 4096x2160@30Hz
This 1x8 DVI splitter enables you to display one DVI source to eight DVI displays simultaneously. It is typically used to connect DVI sources such as DVD players, Blu-ray players, satellite receivers or gaming systems to DVI displays such as HDTVs, HD projectors or DVI monitors. Features
Color: Black
Housing: Metal Enclosure
Operating Temperature: -5 to +45?
Storage Temperature: -15 to +55?
Operating Humidity: 10 to 90%RH (No Condensation)
| Product | 8-Port DVI Video Splitter, Resolution 4096x2160@30Hz |
| Color | Black |
| Housing | Metal Enclosure |
| Operating Temperature | -5 to +45? |
| Storage Temperature | -15 to +55? |
| Operating Humidity | 10 to 90%RH (No Condensation) |
| Storage Humidity | 5 to 95%RH (No Condensation) |
| Video Input Connector | 1 - DVI-D 29-pin Female |
| Video Output Connector | 8 - DVI-D 29-pin Female |
| Max. working current | 1.2A/5V |
| Power Supply | AC 100V?240V 50HZ/60Hz, DC5V/2A/12V |
| DVI Resolution | 4096x2160@30Hz |
| Max. Signal Bandwidth | 340MHz |
| Max. Baud Rate | 3.4Gbps Serial Link |
| Cable Distance | 10 m (Max.) |
| Input/Output TMDS signal | 0.5~1.5Volts p-p(TTL) |
