Thermaltake 600W 80+White Smart Non-Modular ATX Power Supply
Click the image to zoom
Thermaltake 600W 80+White Smart Non-Modular ATX Power Supply
$74.99
In stock
— ships in 1 business day
Description
600W 80+ Certified non-modular ATX12V/EPS12V Power Supply; single 120mm intelligent-cooling fan; active PFC; single +12V rail; connectors include 20+4-pin ATX, 4+4-pin EPS, two PCIe 6+2-pin, six SATA; MTBF over 100,000 hours
Specifications
Thermaltake Smart 600W 80 PLUS Power Supply
Model: PS-SPD-0600NPCWUS-W
Condition: New
| Brand | Thermaltake |
| Series | SMART Series |
| Model | PS-SPD-0600NPCWUS-W |
| Type | ATX12V / EPS12V |
| Power Output | 600W |
| Efficiency Rating | 80 PLUS Certified |
| Efficiency | 80% Typical Efficiency |
| Modular Type | Hardwired (Non-Modular) |
| Cooling Fan | 120mm Intelligent Cooling Fan |
| PFC | Active PFC |
| +12V Rail Design | Single Rail |
| Main Connector | 20+4-Pin ATX |
| CPU Connector | 1 x 4+4-Pin EPS |
| PCIe Connectors | 2 x 6+2-Pin PCIe |
| SATA Connectors | 6 |
| Molex Connectors | 3 |
| Floppy Connector | 1 |
| Input Voltage | 100V - 240V |
| Input Frequency | 50Hz - 60Hz |
| Input Current | 10A Max |
| Output Rail | +12V @ 42A |
| Power Good Signal | 100 - 500 ms |
| Hold-Up Time | 16 ms Minimum at 60% Load |
| Haswell Ready | Yes |
| SLI Ready | Yes |
| CrossFire Ready | Yes |
| MTBF | >100,000 Hours |
| Protection Features | Over Voltage Protection (OVP) |
| Dimensions | 3.40" x 5.90" x 5.50" |
| Weight | 4.40 lbs |
| Certifications | 80 PLUS, CE, CB, TUV, UL, FCC |
| Features | Single +12V Rail, Active PFC, SLI & CrossFire Ready, Intel ATX12V 2.31 Compliant, Intelligent Fan Control |
